SIMATIC S7-1200
|
|
|
CPU Modules
|
Category
CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules |
Model
CPU 1211C DC/DC/DC CPU 1211C AC/DC/Relay CPU 1211C DC/DC/Relay CPU 1212C DC/DC/DC CPU 1212C AC/DC/Relay CPU 1212C DC/DC/Relay CPU 1214C DC/DC/DC CPU 1214C AC/DC/Relay CPU 1214C DC/DC/Relay CPU 1215C DC/DC/DC CPU 1215C AC/DC/Relay CPU 1215C DC/DC/Relay CPU 1217C DC/DC/DC |
Part Number
6ES7 211-1AE40-0XB0 6ES7 211-1BE40-0XB0 6ES7 211-1HE40-0XB0 6ES7 212-1AE40-0XB0 6ES7 212-1BE40-0XB0 6ES7 212-1HE40-0XB0 6ES7 214-1AG40-0XB0 6ES7 214-1BG40-0XB0 6ES7 214-1HG40-0XB0 6ES7 215-1AG40-0XB0 6ES7 215-1BG40-0XB0 6ES7 215-1HG40-0XB0 6ES7 217-1AG40-0XB0 |
Description
6 DI, 4 DO, 2 AI, 24 V DC 6 DI, 4 DO relay, 2 AI 6 DI, 4 DO relay, 2 AI 8 DI, 6 DO, 2 AI, 24 V DC 8 DI, 6 DO relay, 2 AI 8 DI, 6 DO relay, 2 AI 14 DI, 10 DO, 2 AI 14 DI, 10 DO relay, 2 AI 14 DI, 10 DO relay, 2 AI 14 DI, 10 DO, 2 AI, 2 AO 14 DI, 10 DO relay, 2 AI, 2 AO 14 DI, 10 DO relay, 2 AI, 2 AO 30 DI, 30 DO, 2 AI, 2 AO |
Signal Boards (SB)
|
Category
Signal Boards (SB) Signal Boards (SB) Signal Boards (SB) Signal Boards (SB) Signal Boards (SB) Signal Boards (SB) Signal Boards (SB) Signal Boards (SB) Signal Boards (SB) Signal Boards (SB) Signal Boards (SB) |
Model
SB 1221 SB 1221 SB 1221 SB 1222 SB 1222 SB 1222 SB 1222 SB 1231 SB 1231 SB 1231 SB 1232 |
Part Number
6ES7221-3AD30-0XB0 6ES7221-3BD30-0XB0 6ES7221-3BF50-0XB0 6ES7222-1AD30-0XB0 6ES7222-1BD30-0XB0 6ES7222-1BF50-0XB0 6ES7222-5BF50-0XB0 6ES7231-5PA30-0XB0 6ES7231-5QA30-0XB0 6ES7231-5HA30-0XB0 6ES7232-4HA30-0XB0 |
Description
4 DI, 5 V DC, 200 kHz 4 DI, 24 V DC, 200 kHz 8 DI, 24 V DC, 100 kHz 4 DQ, 5 V DC, 200 kHz 4 DQ, 24 V DC, 200 kHz 8 DQ, 24 V DC, 100 kHz 8 DQ, 24 V DC, 100 kHz 1 AI, RTD (Pt100/Pt1000) 1 AI, Thermocouple 4 AI, ±10 V / ±5 V / ±2.5 V / 0-20 mA / 4-20 mA 1 AO, ±10 V / 0-20 mA |
Signal Modules (SM)
|
Category
Signal Modules (SM) Signal Modules (SM) Signal Modules (SM) Signal Modules (SM) Signal Modules (SM) Signal Modules (SM) Signal Modules (SM) Signal Modules (SM) Signal Modules (SM) Signal Modules (SM) Signal Modules (SM) Signal Modules (SM) |
Model
SM 1221 SM 1221 SM 1222 SM 1222 SM 1223 SM 1231 SM 1231 SM 1231 SM 1231 SM 1232 SM 1232 SM 1234 |
Part Number
6ES7221-1BF32-0XB0 6ES7221-1BH32-0XB0 6ES7222-1BF32-0XB0 6ES7222-1HH32-0XB0 6ES7223-1BL32-0XB0 6ES7231-4HD32-0XB0 6ES7231-4HF32-0XB0 6ES7231-5ND32-0XB0 6ES7231-5QF32-0XB0 6ES7232-4HB32-0XB0 6ES7232-4HD32-0XB0 6ES7234-4HE32-0XB0 |
Description
8 DI, 24 V DC, Sink/Source 16 DI, 24 V DC, Sink/Source 8 DO, 24 V DC, Transistor 0.5 A 16 DO, 24 V DC, Transistor 0.5 A 16 DI / 16 DO, 24 V DC, Sink/Source / Transistor 0.5 A 4 AI, ±10 V / ±5 V / ±2.5 V / 0–20 mA / 4–20 mA, 13-bit 8 AI, ±10 V / ±5 V / ±2.5 V / 0–20 mA / 4–20 mA, 13-bit 4 AI, RTD (Pt100/Pt1000), 16-bit 8 AI, Thermocouple (TC), 16-bit 2 AO, ±10 V, 14-bit / 0–20 mA / 4–20 mA, 13-bit 4 AO, ±10 V, 14-bit / 0–20 mA / 4–20 mA, 13-bit 4 AI / 2 AO, ±10 V, 14-bit / 0–20 mA / 4–20 mA, 13-bit |
Communication Modules (CM)
|
Category
Communication Modules (CM) Communication Modules (CM) Communication Modules (CM) Communication Modules (CM) Communication Modules (CM) Communication Modules (CM) |
Model
CM 1241 (RS-232) CM 1241 (RS-485) CM 1242-5 CM 1243-5 CM 1243-1 CM 1244-1 CM 1247-5 |
Part Number
6ES7 241-1CH30-0XB0 6ES7 241-1CH31-0XB0 6GK7 242-5DX30-0XE0 6GK7 243-5DX30-0XE0 6GK7 243-1CX30-0XE0 6GK7 244-1CX30-0XE0 6GK7 247-5DX30-0XE0 |
Description
Serial communication, RS-232 Serial communication, RS-485 PROFIBUS DP slave module PROFIBUS DP master module Industrial Ethernet communication module Point-to-point communication, higher performance PROFIBUS DP master for larger networks |
Special Function Modules (FM)
|
Category
Special Function Modules (FM) Special Function Modules (FM) Special Function Modules (FM) |
Model
SM 1238 Energy Meter FM 350 (Counter) FM 350-2 |
Part Number
6ES7 238-5XA32-0XB0 6ES7 350-1AH03-0AE0 6ES7350-2AH01-0AE0 |
Description
Energy measurement module High-speed counter module (add-on) Counter module with 8 channels, |
Safety Modules / CPUs
|
Category
Safety Modules / CPUs Safety Modules / CPUs Safety Modules / CPUs |
Model
CPU 1212FC CPU 1214FC CPU 1215FC |
Part Number
6ES7 212-1HF40-0XB0 6ES7 214-1HF40-0XB0 6ES7 215-1HF40-0XB0 |
Description
Compact failsafe CPU, 2×DI/2×DO integrated Mid-range failsafe CPU with integrated I/O Higher-performance failsafe CPU with PROFINET |
HMI Panels
|
Category
HMI Panels HMI Panels HMI Panels HMI Panels |
Model
KTP400 Basic KTP700 Basic TP700 Comfort TP900 Comfort |
Part Number
6AV2 123-2GB03-0AX0 6AV2 123-2JB03-0AX0 6AV2 124-0GC01-0AX0 6AV2 124-0JC01-0AX0 |
Description
4" Key + Touch Basic HMI 7" Key + Touch Basic HMI 7" Touch Comfort Panel 9" Touch Comfort Panel |
Accessories
|
Category
Accessories Accessories Accessories Accessories Accessories |
Model
Memory Card 12MB Memory Card 24MB Memory Card 24MB Micro Memory Card 64GB Micro Memory Card 2MB |
Part Number
6ES7954-8LE03-0AA0 6ES7954-8LF02-0AA0 6ES7954-8LF03-0AA0 6ES7954-8LC04-0AA0 6ES7953-8LL31-0AA0 |
Description
12 MB, 3.3V Flash, for S7-1200/1500 CPUs 24 MB, 3.3V Flash, for S7-1200/1500 CPUs 24 MB, 3.3V Flash, for S7-1200/1500 CPUs 64 GB, for S7-300/C7/ET200 2 MB, for S7-300/C7/ET200 |
Software
|
Category
Software Software Software Software Software Software Software Software Software |
Model
TIA Portal Basic TIA Portal Basic TIA Portal Basic TIA Portal Basic TIA Portal Professional TIA Portal Professional TIA Portal Professional STEP 7 Safety Basic STEP 7 Safety Advanced |
Part Number
6ES7822-0AE24-0YA5 6ES7822-1AE23-0YC5 6ES7822-0AA24-0YA5 6ES7822-0AA24-0YE5 6ES7822-1AA24-0YA5 6ES7822-1AA07-0YA5 6ES7822-1AA06-4YA5 6ES7833-1FB23-0YA5 6ES7833-1FA18-0YA5 |
Description
Engineering software for S7-1200/1500, S7-300/400/WinAC, Basic Panels; floating Upgrade to latest version; floating license. Downloadable version; floating license. Upgrade downloadable version; floating license. Professional engineering software for S7-1200/1500, S7-300/400/WinAC; floating license. Professional version combo with TIA Portal; floating license. Professional version combo for training purposes; floating license. Safety engineering software for S7-1200F; floating license. Advanced safety programming software; floating license. |
