SIMATIC S7-400
|
|
|
CPU Modules
|
Category
CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules CPU Modules |
Model
CPU 412-1 CPU 412-2 CPU 412-2 PN CPU 412F-2 (failsafe) CPU 414-2 CPU 414-3 CPU 414-3 PN/DP CPU 414F-3 PN/DP (failsafe) CPU 416-2 CPU 416-3 CPU 416F-2 (failsafe) CPU 416F-3 PN/DP (failsafe) CPU 417-4H / 417-5H CPU 417F-4H / 417F-5H |
Part Number
6ES7 412-1XJ05-0AB0 / 6ES7 412-1XJ07-0AB0 6ES7 412-2XJ05-0AB0 / 6ES7 412-2XJ07-0AB0 6ES7 412-2EK06-0AB0 / 6ES7 412-2EK07-0AB0 6ES7 412-2FK05-0AB0 / 6ES7 412-2FK07-0AB0 6ES7 414-2XK05-0AB0 6ES7 414-3XM05-0AB0 / 6ES7 414-3XM07-0AB0 6ES7 414-3EM06-0AB0 / 6ES7 414-3EM07-0AB0 6ES7 414-3FM06-0AB0 / 6ES7 414-3FM07-0AB0 6ES7 416-2XN05-0AB0 / 6ES7 416-2XP07-0AB0 6ES7 416-3XR05-0AB0 / 6ES7 416-3XR07-0AB0 6ES7 416-2FN05-0AB0 / 6ES7 416-2FN07-0AB0 6ES7 416-3FR05-0AB0 / 6ES7 416-3FR07-0AB0 6ES7 417-4HL04-0AB0 / 6ES7 417-5HT06-0AB0 6ES7 417-4FN04-0AB0 / 6ES7 417-5FT06-0AB0 |
Description
Entry-level CPU, MPI/DP, compact memory Extended memory and performance With integrated PROFINET Failsafe version of CPU 412 Mid-range CPU, MPI/DP Multi-interface CPU PROFINET + PROFIBUS Safety CPU with PN/DP High-performance CPU, large memory Top-tier CPU, max throughput High-performance failsafe CPU Failsafe with PN/DP High-availability redundant CPUs Failsafe + High Availability (H-CPU family) |
Power Supply Units
|
Category
Power Supply Units Power Supply Units Power Supply Units Power Supply Units |
Model
PS 405 2A PS 405 4A PS 405 10A PS 405 20A |
Part Number
6ES7 405-0KA02-0AA0 6ES7 405-0KA01-0AA0 6ES7 405-0KA02-0AA0 6ES7 405-0KA20-0AA0 |
Description
Power supply module, Input 120/230 V AC, Output 24 V DC / 2 A Power supply module, Input 120/230 V AC, Output 24 V DC / 4 A Power supply module, Input 120/230 V AC, Output 24 V DC / 10 A Power supply module, Input 120/230 V AC, Output 24 V DC / 20 A |
Racks / Backplanes
|
Category
Racks / Backplanes Racks / Backplanes Racks / Backplanes Racks / Backplanes Racks / Backplanes Racks / Backplanes Racks / Backplanes |
Model
UR1 UR2 UR2-H ER1 ER2 IM 460 IM 461 |
Part Number
6ES7 400-1JA00-0AA0 6ES7 400-1JB00-0AA0 6ES7 400-1JH01-0AA0 6ES7 400-1EA00-0AA0 6ES7 400-1EB00-0AA0 6ES7 460-0AA01-0AA0 6ES7 461-0AA01-0AA0 |
Description
Central rack, 4 slots (smallest S7-400 rack) Central rack, 9 slots (standard S7-400 rack) Central rack, 9 slots, high feature version for redundant systems Expansion rack, 4 slots Expansion rack, 9 slots Interface module for central rack (master), connects to IM 461 Interface module for expansion rack (slave), connects to IM 460 |
Digital I/O Modules
|
Category
Digital I/O Modules Digital I/O Modules Digital I/O Modules Digital I/O Modules Digital I/O Modules Digital I/O Modules Digital I/O Modules Digital I/O Modules Digital I/O Modules Digital I/O Modules |
Model
SM 421 (Digital Input) SM 421 SM 421 SM 421 SM 421 SM 422 (Digital Output) SM 422 SM 422 SM 422 SM 422 |
Part Number
6ES7-421-7BH01-0AB0 6ES7-421-7DH00-0AB0 6ES7-421-1BL00-0AA0 6ES7-421-1BL01-0AA0 6ES7-421-1EL00-0AA0 6ES7-422-5EH00-0AB0 6ES7-422-5EH10-0AB0 6ES7-422-1BL00-0AA0 6ES7-422-1BH10-0AA0 6ES7-422-5EH10-0AB0 |
Description
16 DI, 24 V DC, isolated; 0.05 ms input delay; alarm & diagnostics. 16 DI, Universal Voltage (UC 24-60V), alarm & diagnostics. 32 DI, 24 V DC. 32 DI; isolated; typically 24 V DC. 32 DI, 120 V DC / AC. 16 DO; AC 120 V / 2 A; diagnostics. 16 DO; DC 20-125 V; 1.5 A; isolated groups; diagnostics. 32 DO; 24 V DC; 0.5 A per output. 16 DO; 24 V DC; 2 A; isolated in two groups of 8. 8 outputs AC 120/230 V, 5 A. |
Analog I/O Modules
|
Category
Analog I/O Modules Analog I/O Modules Analog I/O Modules Analog I/O Modules Analog I/O Modules Analog I/O Modules Analog I/O Modules Analog I/O Modules |
Model
SM 431 Analog Input SM 431 Analog Input SM 431 Analog Input SM 431 Analog Input SM 431 Analog Input SM 431 Analog Input SM 431 Analog Input SM 432 Analog Output |
Part Number
6ES7-431-0HH00-0AB0 6ES7-431-1KF00-0AB0 6ES7-431-1KF10-0AB0 6ES7-431-1KF20-0AB0 6ES7-431-7QH00-0AB0 6ES7-431-7KF00-0AB0 6ES7-431-7KF10-0AB0 6ES7-432-1HF00-0AB0 |
Description
16 AI, 13-bit resolution, non-isolated inputs: ±10 V, ±20 mA, 4-20 mA, ~20 ms 8 AI, isolated, 13-bit, U/I/R (Voltage / Current / Resistive / RTD / Thermocouple) 8 AI, isolated, 14-bit, improved linearization etc. 8 AI, isolated, 14-bit, faster conversion (~0.416 ms cycle), etc. 16 AI, 16-bit (15 +1), with diagnostics & linearization for RTD / thermocouples 8 AI, 16-bit with isolation, more precise/advanced features. 8 AI, 16-bit, likely a variant for RTD / thermal measurement etc. 8 AO, 13-bit resolution, isolated, voltage/current output U/I. |
Function Modules
|
Category
Function Modules Function Modules Function Modules |
Model
FM 450 PID FM 451 Counter FM 458A |
Part Number
6ES7 450-1AA01-0AE0 6ES7 451-1AA01-0AE0 6ES7 458-3AA01-0AE0 |
Description
PID Control module, dedicated closed-loop control functions High-speed counter module for S7-400 Advanced function module, high-performance arithmetic and control tasks |
Communication Modules
|
Category
Communication Modules Communication Modules Communication Modules Communication Modules Communication Modules Communication Modules |
Model
CP 441-1 CP 443-1 CP 443-1 IT CP 443-5 CP 444-5 EXT CP 443-2 |
Part Number
6ES7 441-1AA03-0AE0 6GK7 443-1EX30-0XE0 6GK7 443-1GX20-0XE0 6GK7 443-5FX00-0XE0 6GK7 444-5EX03-0XE0 6GK7 443-2AX01-0XE0 |
Description
Serial communication module (point-to-point, RS-232/422/485) Industrial Ethernet communication processor Ethernet with IT functions (HTTP, FTP, Email, SNMP) PROFIBUS DP communication processor Extended PROFIBUS DP communication processor (multi-master) Communication processor for AS-Interface (AS-i) networks |
Redundancy / High Availability
|
Category
Redundancy / High Availability Redundancy / High Availability Redundancy / High Availability Redundancy / High Availability Redundancy / High Availability |
Model
CPU 414H CPU 417H CPU 41xH (general) Sync Module IM 467 |
Part Number
6ES7 414-4HM06-0AB0 6ES7 417-4HT06-0AB0 (414H, 416H, 417H series) 6ES7 400-7XA01-0AB0 6ES7 467-0AA00-0AA0 |
Description
Redundant CPU for S7-400H systems, supports hot standby High-performance redundant CPU for S7-400H systems H-system CPUs with redundancy and synchronization features Synchronization module, used for connecting redundant CPUs Interface module for connection of redundant central |
Safety Modules
|
Category
Safety Modules Safety Modules Safety Modules Safety Modules Safety Modules |
Model
F-CPUs (Fail-Safe) F-CPUs (Fail-Safe) F-CPUs (Fail-Safe) F-DI Fail safe F-DO Fail safe |
Part Number
6ES7 414-4FN05-0AB0 (CPU 414F) 6ES7 416-5FN05-0AB0 (CPU 416F) 6ES7 417-5FN05-0AB0 (CPU 417F) 6ES7 421-7FD00-0AB0 6ES7 422-7FD00-0AB0 |
Description
Fail-safe CPUs for S7-400F systems, integrated safety functions (SIL3 / PL e) Fail-safe CPUs for S7-400F systems, integrated safety functions (SIL3 / PL e) Fail-safe CPUs for S7-400F systems, integrated safety functions (SIL3 / PL e) Digital input module, fail-safe, for safety-related signals Digital output module, fail-safe, shuts down actuators safely |
Accessories
|
Category
Accessories Accessories Accessories Accessories |
Model
MMC (Memory Cards) Interface Cables Interface Cables Wiring / Mounting Kits |
Part Number
6ES7 953-8LGxx-0AA0 6ES7 901-3CB30-0XA0 6ES7 901-4CA00-0AA0 6ES7 193-4CA50-0AA0 |
Description
Micro Memory Cards used for program and data storage in S7-400 CPUs Programming / communication cables for CPU connection Programming / communication cables for CPU connection Wiring, terminal blocks, and mounting accessories for I/O modules |
Software
|
Category
Software Software |
Model
STEP 7 (Classic) PCS 7 (Process Control) |
Part Number
6ES7 810-4CA13-0YA5 6ES7 810-4CA14-0YA5 (Base system) |
Description
Standard programming software for SIMATIC S7-300/400 (Classic version: LAD, FBD, STL, HW Config, NetPro, diagnostics) Siemens process control system built on STEP 7, WinCC, and libraries for S7-400 process automation |
